Monte Rosa

Monte Rosa

The Monte Rosa spa has all the features required of a premium category spa: the MyMusic™ sound system, SmartPhone application with WiFi connection, 3 pcs 3 horsepower massage pumps, 3 pcs MicroPlus paper filters, and aromatic therapy.

PRODUCT SPECS
Dimensions	91 × 91 × 37 in
Seats	1 reclining places, 5 sitting places
Net weight / Water volume	904 lbs / 396 gallons
Frame	WPS
Side cover	StarSide™ UV-proof wood textured
Reinforcement	Polyurethane
Insulation	Polyfoam (1.4 in/0.4 in)
Drains	1 pc at the bottom

POWER REQUIREMENT
	240V 60Hz 48A

MASSAGE SYSTEM
Control box	Gecko (IN.YE-5)
Control panel	SmartTouch (K-1000)
Total number of jets	64 pcs
Laminar fountain jets	2 pcs lighting
Heater	4 kW
Pumps	3 pcs 3 HP single speed
Circulation pump	W-EC Pump (0,25 kW)

WATER CARE
Filtration	3 pcs MicroPlus paper filter
Water sanitization	UV-C + Ozone

COMFORT SOLUTIONS
LED lights	13 pcs LED + Central
	+ StarLight™ corner element lighting
Headrests	3 pcs
MyMusic™ 2.1 Sound System	2 pcs oval pop-up speakers
	+1 subwoofer

PREMIUM SOLUTIONS
SmartPhone app - wifi connection	yes
Aromatic therapy	Liquid Aroma
Thermo cover	yes (standard 5-3,5 in, Scandinavian 6-5 in)
Type	Kilimanjaro

Button
Button
Button
Button
Button

Resources

Download the wiring diagram

Model specifications

Monte Rosa user guide

Available Colors for This Model

Sterling Silver Shell:

Grey Cabinet
Button
Brown Cabinet
Button
Black Cabinet
Button

Midnight Canyon Shell:

Grey Cabinet
Button
Brown Cabinet
Button
Black Cabinet
Button

Tuscan Sun Shell:

Grey Cabinet
Button
Brown Cabinet
Button
Black Cabinet
Button

Standard Specifications

Energy-efficient water circulation
The W-EC circulation pump is a very low power consumption (190W/h) device which is available for all of our hot tubs as an option. The low power consumption (40% lower energy costs than a typical circulation pump) long-life and almost silent running make this a very “green” and cost effective option to consider.
Button
UV-C water sanitization
• Ensures fresh, clean and clear water • Disinfects water efficiently and safely • Bound chlorine is broken down by UV-C light • Protects your water from germs • Can reduce the use of chorine and other chemicals by up to 80% • Prevents the smell of chlorine and avoids irritation of the skin and eyes (red eyes)
Button
WPS cabinet frame
Immortality for the spa cabinet`s frame! The special mixture of hardwood and plastic ensures exceptional stability and life for the Spa’s structural frame – protecting and extending the life of your investment even further.
Button
Aromatic therapy
Enjoy the relaxing effects of aromatic infusions in your WELLIS spa, adding the power of your favorite fragrances to your hydrotherapy experience - which is sure to result in a better mood!
Button
Colour therapy mood lighting
Our exclusive system is based upon lights of four different colours: green, yellow, blue and red. These can be set to fade gently through the spectrum or, by a simple touch of the spa’s control panel can be fixed on the single colour most beneficial to your mood. It includes one underwater lamp with 55 LEDs.
Button
Exclusive multipoint lighting
The exclusive WELLIS on-demand colour therapy moodlighting, includes 10 to 20 water line led point lights within the bathing area.
Button
AQUASOUL™ sound system
The Wellis AquaSoul™ Pro 4.1 and 2.1 sound system features the newly developed, top quality waterproof elements. You no longer need to bother with CDs, MP3 players or connect any other external devices through a USB cable because the built-in receiver can be reached via Bluetooth even via your mobile phone.
Button
Wellis SmartPhone application
The SmartPhone application is a brand new development for our massage pools. Immediate access and remote control. You can access the control system of your WELLIS spa any time from anywhere. You can set the water temperature and circulation and you can even check the current status of the spa.
Button
Thermal cover
The thermal cover is designed to keep the heat of the spa at the set level, which can save you a lot of energy and money. Thermal insulation is provided by a special foam covered with stylish UV-resistant artificial leather.
Button
Fountain jets
2-3 fountain jets triple the fun and design in your spa.
Button
Smart touch control panel
Full featured keypad with color capacitive touch screen display.
Button

Available Options for This Product

Button

Wellis Easy Step

Maintenance-free spa step. weight: 16,7 lbs; made of UV resistant plastic; anti-slip rubber treads; size: 28" × 24" × 17"

Button

Hollywood Lighting Pack

The Hollywood Lighting Pack includes LED lighting chromotherapy hydromassage jets instead of the regular hydrotherapy jets.

Button

Easy cover lifter

Hot tub thermal cover can be heavy. Protect it and your back by choosing a Wellis cover lifter. This simple to use accessory allows only one person to remove and and replace the Hot tub cover easily and safely. (Also suitable with Xtreme™ winter covers!)
